Mainly used for advertising industry(stainless metal and carbon steel), sheet metal industry(carbon steel),
packaging industry(die board) and so on
Working Area | 1300mm*2500mm |
Working Table | Blade or Sawtooth Blade |
Working speed | 0-400mm/s |
Laser Type | Sealed co2 laser tube |
Laser Power | 130W/150W |
Positioning Accuracy | ±0.05mm(without red dot) |
Image Format Supported | BMP,PLT,DST,AI,DXF,etc |
Cooling System | Constant temperature water cooling and protecting system |
Power Supply | AC220±10%,50-60Hz,30A max |
Driving Motor | Servo motor |
Working Temperature | 0-45℃ |
Working Humidity | 5%-95% |
Whole Machine Dimension | 3460mm*2000mm*1160mm |
Packing size | 3570mm*2020mm*1400mm |
Smoke Exhausting | By Funnel |
Auxiliary cutting gas | Nitrogen,oxygen or air |
150w cutting speed | |
1mm | 1800mm/min |
1.5mm | 1000-1800m/min |
Carbon steel | |
1mm | 1800mm/min |
1.5mm | 1000-1800m/min |
Acrylic | |
10mm | 300mm/min |
20mm | 90-120mm/min |
PVC board | |
10mm | 300-400mm/min |
1.Mixed-cut:metal-Stainless steel, carbon steel and non-metal-acrylic, board
2.High precision:Imported servo with imported ball screw transmission greatly improve the response speed and cutting precision of equipment, extend the life time
3.Constant light system: first apply the constant light, achieving high precision cutting of the whole area
